| Processor | Industrial-grade processor |
| IP Camera Input | 128 channel |
| Operating System | Embedded LINUX |
| User Interface | Web, Local GUI |
| Video Output | 2 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; 4 HDMI 1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1–4) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K, max. resolution of HDMI4 is 1080p |
| Encode Strategy | Instastream, H.264+ |
| Video Compression | H.265, H.264 |
| Audio Input | 1 Channel RCA |
| Audio Output | 2 Channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726, AAC |
| ANPR by Camera (Number of Channels) | All Channels (64 targets/s) |
| License Plate Database Capacity | 1. Up to 20,000 plate numbers. 2. Blocklist and allowlist |
| Perimeter Performance AI by NVR | Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode |
| Perimeter Performance of AI by Camera | All Channels (64 targets/s) |
| AI by Camera | Face detection, Face recognition, Video metadata (Human, Motor vehicles and Non-motor vehicles), Perimeter protection, SMD, Stereo analysis, Crowd distribution, People counting, ANPR, Heat map, PPE detection |
| SMD Plus by NVR | 32 Channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera | All Channels (128 targets/s) |
| IntelliCheck AI by Camera + Recorder | Max. 64-channel, 1 combined event per channel |
| AI by NVR | Face detection, Face recognition, Video metadata (Human, Motor vehicles and Non-motor vehicles), Perimeter protection, SMD Plus |
| Face Attributes | 6 Attributes |
| Face Detection AI by NVR | Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode |
| Face Detection By Camera | 64 Channels |
| Face Database Capacity | Up to 40 face databases with 300,000 images, with a total capacity of 48 G. |
| Face Recognition AI by NVR | Simultaneous mode: 32-channel FD (by camera) + FR (by recorder), image stream: 32 face images/s; 8- channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s; 5- channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode |
| Face Recognition AI by Camera | 64 Channels |
| Metadata Performance of AI by NVR | 8 Channels, 23 Attributes extraction |
| Metadata Performance of AI by Camera | 64 Channels |
| Motor Vehicle Attributes | 9 Attributes |
| Non-motor Vehicle Attributes | 4 Attributes |
| Network Bandwidth | AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing |
| Multi-screen Display | Main Screen: 1/4/8/9/16/25/36/64, Sub Screen: 1/4/8/9/16/25/36 |
| Resolution | 32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2MP, 960P, 720P, D1, CIF |
| Multi-channel Playback | Up to 16 Channels |
| Decoding Capability | AI disabled: 2 Channel 32 MP@30 fps, 2 Channel 24 MP@30 fps, 4 Channel 16 MP@30 fps, 5 Channel 12 MP@30 fps, 8 Channel 8 MP@30 fps, 11 Channel 6 MP@30 fps, 12 Channel 5MP@30 fps, 16 Channel 4 MP@30 fps, 32 Channel 1080p@30 fps, 128 Channel D1@30 fps AI enabled: 1 Channel 32 MP@30 fps, 1 Channel 24 MP@30 fps, 2 Channel 16 MP@30 fps, 2 Channel 12 MP@30 fps, 4 Channel 8 MP@30 fps, 5 Channel 6 MP@30 fps, 6-channel 5 MP@30 fps, 8 Channel 4 MP@30 fps, 16 Channel 1080p@30 fps, 80 Channel D1@30 fps |
| Record Mode | General, Motion detection, Intelligent, Alarm, POS |
| Playback Mode | Instant playback, General playback, Event playback, Tag playback, Smart playback |
| Alarm Input | 32 Channels |
| Alarm Output | 16 Channels |
| General Alarm | Motion detection, Local alarm, Alarm box, Camera external alarm, Network alarm, Scene changing, PIR alarm, Thermal alarm |
| Abnormality Alarm | Error (No disk, Disk error, Low space, RAID exception, Low quota space, Abnormal disk health, Network disconnection, IP conflict, MAC conflict, Abnormal fan speed), Video loss, Video tampering, Camera offline, Audio detection |
| Intelligent Alarm | Face detection, Face and body detection, Face recognition, Perimeter protection, SMD, Video metadata, Stereo analysis, Crowd distribution, ANPR, Heat map |
| Alarm Linkage | Record, Snapshot (panoramic), Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Email |
| Smart Phone | Ios, Android |
| RAID | RAID 0/1/5/6/10 |
| Hot Swapping | Support |
| Hard Disk | 16 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature |
| Interface Ports | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports), 1 RS232, 1 eSATA port, 2 RS485 (1 port for halfduplex serial communication, 1 port for full-duplex serial communication |
| Disk Group | Support |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, Multicast, InstaOn, Auto Registration, Iscsi, ONVIF 22.06(Profile T, Profile S, Profile G), CGI, SDK |
| Ethernet | 4 (10/100/2500 Mbps Ethernet port, RJ-45) |
| Network Mode | Multi-address, Load balance, Fault tolerance |
| Backup Method | USB device and network |
| Browser | Chrome, IE, Safari, Edge, Firefox |
| Power Supply | 100–240V AC, 50±2% Hz |
| Redundant Power | Support |
| Power Consumption | |
| Operating Temperature | -10 °C to +55 °C (14 °F to +131 °F) |
| Operating Humidity | 10%–93% |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Dimensions | 485.0mm × 529.0mm × 133.2mm |
| Weight | 13.03 kg (without HDD) |
