| Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| IP Camera Input | 64 channel |
| User Interface | Web, Local GUI |
| AI by Camera | Face detection, Face recognition, Video metadata (Human, motor vehicles and Non-motor vehicles), Perimeter protection, SMD, Stereo analysis, Crowd distribution, People counting, ANPR, Heat map, PPE detection |
| AI by NVR | Face detection, Face recognition, Video metadata (Human, Motor vehicles and Non-motor vehicles), Perimeter protection, SMD Plus |
| Perimeter Performance AI by NVR | Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode |
| Perimeter Performance of AI by Camera | 64 Channels |
| Video Output | 2 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; 4 HDMI 1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports) Max. resolution of VGA1 and VGA2 is 1080P, Max. resolution of HDMI1 and HDMI2 is 4K, Max. resolution of HDMI3 is 8K, Max. resolution of HDMI4 is 1080P Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1–4) Max. resolution of VGA1 and VGA2 is 1080P, Max. resolution of HDMI1, HDMI2 and HDMI3 is 4K, Max. resolution of HDMI4 is 1080P |
| SMD Plus by NVR | 32 Channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD By Camera | All channels (128 targets/s) |
| Encode Strategy | Instastream, H.264+ |
| Video Compression | H.265, H.264 |
| Resolution | 32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2MP, 960P, 720P, D1, CIF |
| Hot Swapping | Support |
| Video Metadata By Camera for Non Vehicle | 4 Attributes |
| Decoding Capability | AI disabled: 2 Channel 32 MP@30 fps, 2 Channel 24 MP@30 fps, 4 Channel 16 MP@30 fps, 5 Channel 12 MP@30 fps, 8 Channel 8 MP@30 fps, 11 Channel 6 MP@30 fps, 12 Channel 5 MP@30 fps, 16 Channel 4 MP@30 fps, 32 Channel 1080p@30 fps, 64 Channel D1@30 fps AI enabled: 1 Channel 32 MP@30 fps, 1 Channel 24 MP@30 fps, 2 Channel 16 MP@30 fps, 2 Channel 12 MP@30 fps, 4 Channel 8 MP@30 fps, 5 Channel 6 MP@30 fps, 6 Channel 5 MP@30 fps, 8 Channel 4 MP@30 fps, 16 Channel 1080p@30 fps, 80 Channel D1@30 fps |
| General Alarm | Motion detection, Local alarm, Alarm box, Camera external alarm, Network alarm, Scene changing, PIR alarm, Thermal alarm |
| Intelligent Alarm | Face detection, Face and body detection, Face recognition, Perimeter protection, SMD, Video metadata, Stereo analysis, Crowd distribution, ANPR, Heat map |
| Abnormality Alarm | Error (No Disk, Disk error, Low space, RAID exception, Low quota space, Abnormal disk health, Network disconnection, IP conflict, MAC conflict, Abnormal fan speed), Video loss, Video tampering, Camera offline, Audio detection |
| Network Bandwidth | AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing |
| Multi Screen Preview | Main Screen: 1/4/8/9/16/25/36/64 Sub Screen: 1/4/8/9/16/25/36 |
| IntelliCheck AI by Camera + Recorder | Max. 64 Channel, 1 Combined event per Channel |
| ANPR by Camera (Number of Channels) | 64 channels |
| Metadata Performance of AI by NVR | 8 Channels, 23 Attributes extraction |
| Metadata Performance of AI by Camera | 64 Channels |
| Multi-channel Playback | Up to 16 Channels |
| Face Attributes | 6 Attributes |
| Face Database Capacity | Up to 40 face databases with 300,000 images, with a total capacity of 48 G. |
| People Attributes | 9 Human Body Attributes |
| Motor Vehicle Attributes | 9 Attributes |
| Network Mode | Multi-address, load balance, fault tolerance |
| Face Detection AI by Camera | 64 Channels |
| Face Detection AI by NVR | Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode |
| Face Recognition AI by Camera | 64 Channels |
| Face Recognition AI by NVR | Simultaneous mode: 32 Channel FD (by Camera) + FR (by Recorder), image stream: 32 face images/s, 8 Channel FD (by Recorder) + FR (by Recorder), video stream: 16 face images/s Heterogeneous mode: 16 Channel FD (by Camera) + FR (by Recorder), image stream: 16 face images/s, 5 Channel FD (by Recorder) + FR (by Recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode |
| Alarm Linkage | Record, Snapshot (Panoramic), Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Emai |
| Interface Ports | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports), 1 eSATA, 1 RS232, 2 RS485 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) |
| Audio Input | 1 Channel RCA |
| Audio Output | 2 Channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726, AAC |
| Alarm Input | 32 Channels |
| Alarm Output | 16 Channels |
| Disk Interface | 16 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperatu |
| Disk Group | Support |
| RAID | RAID 0/1/5/6/10 |
| Power Redundancy | Support |
| Recording Playback | Instant playback, General playback, Event playback, Tag playback, Smart playback |
| Recording Mode | General, Motion detection, Intelligent, Alarm, POS |
| Ethernet Port | 4 (10/100/2500 Mbps Ethernet port, RJ-45) |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, Multicast, InstaOn, iSCSI, ONVIF 22.06(Profile T, Profile S, Profile G), CGI, SDK |
| Backup Mode | USB device and network |
| License Plate Database Capacity | 1. Up to 20,000 plate numbers, 2. Blocklist and allowlist |
| Browser | Chrome, IE, Safari, Edge, Firefox |
| Smart Phone | iOS, Android |
| Power Supply | 100–240 VAC, 50±2% Hz |
| Power Consumption | |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–93% (RH), non-condensing |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Dimensions | 485.0mm × 529.0mm × 133.2mm |
| Weight | 13.03 kg (without HDD) |
