| Image Sensor | 1/2.7 |
| Minimum Illumination | 0.006 [email protected](Color,30IRE), 0.0006 [email protected](B/W,30IRE), 0 lux (IR on) |
| Effective Pixels | 3840 (H) × 2160 (V) |
| Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
| RAM | 512 MB |
| ROM | 128 MB |
| White Balance | Auto, natural, street lamp, outdoor, manual, regional custom |
| Lens | 2.7mm–13.5mm |
| Lens Type | Motorized Lens |
| Gain Control (AGC) | Auto |
| Iris Control | Fixed |
| Max. Aperture | F1.6 |
| Lens Mount | M14 |
| Close Focus Distance | 0.8m |
| DORI Distance | Lens W: 44.1Mtr. (Detect), 17.7Mtr.(Observe), 8.8Mtr. (Recognize), 4.4Mtr(Identify) Lens T: 144.8Mtr(Detect), 57.9Mtr(Observe), 29.0Mtr(Recognize), 14.5Mtr(Identify) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Angle of view | Horizontal: 109°–30°, Vertical: 56° –17°, Diagonal: 131° –35° |
| Stream Capability | Quad Stream |
| S/N Ratio | >56 dB |
| Video Format | PAL /NTSC |
| Video Compression | Instastream, H.265, H.264 H.264H, H.264B, MJPEG (Only supported by the sub stream) |
| AI Coding | AI H.265, AI H.264 |
| IR | IR Range of 60 Mtr. |
| IR Control | Auto/Zoomprio/Manual |
| Resolution | 8M (3840 × 2160), 5M (3072 × 1728), 5M (2592 × 1944), 4M (2688 × 1520), 3M (2048 × 1536/ 2304 × 1296), 2M (1920 × 1080), 1.3M (1280 × 960),1M (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| Smart IR | Support |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080P resolution and lower |
| IR Number | 4 IR LED |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.265: 3 kbps–6144 kbps, H.264: 3 kbps–6144 kbps |
| Mirror Function | Support |
| Noise Reduction | 3D DNR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Privacy Mask | 4 Areas |
| Audio Input | 1 Channel (RCA port) |
| Audio Output | 1 Channel (RCA port) |
| Audio Compression | PCM, G.711a, G.711Mu, G.726 |
| Audio | Built-in Mic |
| Alarm IN | 1 channels in: 5mA 3V–5V DC |
| Alarm Out | 1 channel out: 300mA 12V DC |
| OSD | Camera title, Date & Time |
| Protocol | SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V1/ V2/ V3/, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T) , unicast, multicast |
| IVS (Optional) | Tripwire, Intrusion, Object Abandon/ Missing, SMD, Face Detection |
| Ethernet | RJ-45 (10/100 Enhancement Base-T) |
| Day/Night | Auto(ICR)/Color/B/W |
| Alarm Event | No SD card, SD card full, SD card error, Network disconnection, IP conflict, Motion detection, Video tampering, Defocus detection |
| Cyber Security | AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot. |
| Defog | Support |
| Scene Self-adaptation(SSA) | Support |
| Frame Rate | Main stream: 8MP/5MP/4MP/2MP/1.3MP/720P@1–25/30 fps Sub stream 1: D1/VGA/CIF@1–10 fps Sub stream 2: 1080p/1.3MP/720P@1–15fps Sub stream 3: D1/VGA/CIF@1–10 fps |
| Storage | SFTP, NAS, Micro SD card (support max. 512 GB) |
| User/ Host | 20 (Total bandwidth: 80 M) |
| Browser | Microsoft, Edge and Chrome |
| Certificates | ISO9001 |
| Power Source | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 1.6 W (12 VDC), 3.2 W (PoE) Max. (H.265+ WDR +IR on): 9.6 W (12 VDC), 10.8 W (PoE) |
| Weatherproof Standard | IP67, IK10 |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ≤95% RH, non-condensing |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | 10%–95% RH, non-condensing |
| Casing | Metal + Plastic |
| Dimension | 273.2mm × 95.0mm × 95.0mm |
| Weight | 1.10 kg |
