| Image Sensor | 1/2.5” 6MP PS CMOS Image Sensor (1.016 centimeters) |
| Minimum Illumination | 0.005 [email protected] (Color, 30 IRE), 0.0005 [email protected] (B/W, 30 IRE), 0 lux (IR on) |
| Effective Pixels | 2560 (H) × 2560 (V) |
| Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| RAM | 1 GB |
| ROM | 4 GB |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| Lens | 1.68 mm |
| Gain Control (AGC) | Auto/Manual |
| Lens Type | Fixed-focal |
| Iris Control | Fixed |
| Max Aperture | F2.0 |
| Lens Mount | M12 |
| Close Focus Distance | 0.3 m |
| IR Control | Auto/Manual |
| DORI Distance | Lens 1.68 mm: 33.6m (Detect), 13.4m (Observe), 6.7 m (Recognize), 3.4 m (Identify) |
| Back Light Comp. | BLC/ HLC/ WDR(120dB)/IS |
| Angle of View | H: 185°, V: 185°, D: 185° |
| Stream Capability | Triple Stream |
| S/N Ratio | > 56 dB |
| Resolution | 6M (2560 × 2560), 4M (2048 × 2048), 2M (1440 × 1440), 1.6M (1280 × 1280), 1M (1024 × 1024), (720 × 720), SVCD (480 × 480) |
| Noise Reduction | 2D NR & 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| IR | IR Range of 20 Mtr. |
| IR Number | 3 IR LED |
| Bit Rate Control | VBR/CBR/ABR |
| Bit Rate | H.265: 3 kbps–16384 kbps , H.264: 3 kbps–16384 kbps |
| Video Format | PAL/NTSC |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream) |
| Image Rotation | 0°/180° |
| Smart Compression | AI Instastream, AI H.264 |
| Frame Rate | Max Resolution in O Mode by Default Main stream: 6MP(2560 × 2560)@1–25/30 fps, sub stream: 2MP(1440 × 1440)@1–25/30 fps, third stream: 2MP(1440 × 1440)@1–25/30 fps Resolution of 2 Split Windows in 2P Mode: Sub stream: Panoramic View and Split Window: (1920 × 1440)@1– 25/30 fps, (640 × 480)@1–25/30 fps, (320 × 240)@1– 25/30 fps, third stream: Panoramic View and Split Window: (1920 × 1440)@1– 25/30 fps, (640 × 480)@1 –25/30 fps, (320 × 240)@1– 25/30 fps, Resolution of 2 Split Windows in 2R Mode: Sub stream: Panoramic View and Split Window: (2560 × 960)@1– 25/30 fps, (1280 × 480)@1–25/30 fps, (640 × 240)@1– 25/30 fps, third stream: Panoramic View and Split Window: (2560 × 960)@1– 25/30 fps, (1280 × 480)@1 –25/30 fps, (640 × 240)@1– 25/30 fps, Resolution of 4 Split Windows in 4R Mode: sub stream: Panoramic View and Split Window: (1920 × 1440)@1– 25/30 fps, (640 × 480)@1–25/30 fps, (320 × 240)@1– 25/30 fps, third stream: Panoramic View and Split Window: (1920 × 1440)@1– 25/30 fps, (640 × 480)@1 –25/30 fps, (320 × 240)@1– 25/30 fps |
| Mirror Function | Support |
| Privacy Mask | 4 areas |
| Audio | Built-in Mic |
| Built-in Speaker | Support |
| EPTZ | Support |
| Day/Night | Auto(ICR)/Color/B/W |
| Alarm Event | No SD card, SD card full, SD card error, Network disconnection, IP conflict, Motion detection, Video tampering, Scene changing, Tripwire, Intrusion, Audio detection, Intensity change, Voltage detection, External alarm, People counting in area, Stay detection, People counting, Abnormal number of people detection, Security exception |
| Intelligent Scene Adaption (ISA) | AI ISA |
| Cyber Security | Video encryption, Firmware encryption, Configuration encryption, Digest, WSSE, Account lockout, Security logs, IP/MAC filtering, syslog, HTTPS, 802.1x, Trusted boot, Trusted execution, Trusted upgrade, Session security, Security warning |
| OSD | Camera title, Date & Time |
| Protocol | SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast |
| IVS (Optional) | Tripwire, Intrusion |
| SDK and API | Support |
| Intelligent Scene Adaption (ISA) | Support |
| Decoding Mode | Front-dewarp, Back-dewarp |
| Display Mode | Front-dewarp (hardware decoding): 1O, 1P, 2P, 1R, 2R, 4R, 1O+ 3R 2P/2R: Supports split screen for 2 windows. 4R: Supports split screen for 4 windows |
| Heat Map | Support |
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) |
| Audio Input | 1 Channel (RCA port) |
| Audio Output | 1 Channel (RCA port) |
| Audio Compression | PCM, G.711a, G.711Mu, G.726, G.723, AAC |
| Ethernet | RJ-45 (10/100 Base-T) |
| Alarm IN | 1 Channel in: 5mA 3V–5 VDC |
| Alarm Out | 1 Channel out: 300 mA 12 VDC |
| Weatherproof Standard | IP67, IK10 |
| Storage | SFTP, NAS, Mirco SD card (Max. 512GB) |
| User/Host | 20 users |
| Browser | Microsoft, Edge and Chrome |
| Operating Temperature | –30 °C to +60 °C (–22°F to +140 °F) |
| Operating Humidity | ≤95% RH, non-condensing |
| Storage Temperature | –30 °C to +60 °C (–22 °F to +140°F) |
| Storage Humidity | ≤95% (RH), non-condensing |
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. |
| Certificates | ISO9001 |
| Power Consumption | Basic: 1.4 W (12 VDC), 2.6 W (PoE), Max.: 8.1 W (12 VDC), 10.1 W (PoE) (ICR switch + IR intensity) |
| Power Source | 12 VDC, 1 A, PoE (802.3af) |
| Casing | Metal + Plastic |
| Dimensions | 122 mm × 53.3 mm |
| Weight | 0.46 kg |
