| Image Sensor | Supports installation with universal mounting bracket, or side-mounted on pole with mounting bracket |
| Effective Pixels | 2688 (H) × 1520 (V) |
| Minimum Illumination | 0.0001 Lux |
| Shutter Speed | Auto/Manual 1/50 s–1/100,000 s |
| White Balance | Auto, Manual, Outdoor, Natural, Street Lamp, Partial white balance |
| Lens Type | Motorized vari-focal |
| Max. Aperture | Max. F1.2 |
| Lens | 10 mm-50 m |
| Video Compression | H.265, H.264M, H.264H, H.264B, MJPEG |
| Back Light Compensation | BLC/ HLC/ WDR(140dB |
| S/N Ratio | > 56 dB |
| Angle of view | Horizontal: 10°–44°, Vertical: 6°–24°, Diagonal: 12°–51° |
| Resolution | 4M (2688 × 1520), 1080p (1920 × 1080), UXGA (1600 × 1200), 720p (1280 × 720), D1 (704 × 576), CIF (352 × 288) |
| Frame Rate | Max. 30 fps Main stream (2688 × 1520@30 fps), sub stream (1600 × 1200@30 fps) |
| Noise Reduction | 2D NR, 3D NR |
| Video Format | PAL/ NTSC |
| IR LED | Support |
| IR | IR Range of 30 Mt |
| IR lane covered | 1–2 lanes |
| IR Number | 4 IR (850 nm LED illuminators, adjustable brightness) |
| Day/Night | Supports ICR auto switch: IR cut-off filter (IRCF) with the polarizing filter is used during the daytime, and switches to the IR transmitting filter at night |
| Image Resolution | 2688 (H) × 1520 (V) (OSD black background is not calculated in the pixels) |
| Protocol | SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T) , unicast, multicast |
| Bit Rate | H.264: 32 kbps–32767 kbps, H.265: 32 kbps–32767 kbps, MJPEG: 512 kbps–32767 kbps |
| Bit Rate Control | CBR/VBR |
| Exposure Mode | Auto, Manual (Select from shutter values or customize shutter range) |
| Speed Detection Range | 0 km/h–180 km/h |
| SDK and API | Support |
| Ethernet | 1 × RJ-45 Ethernet port, 10/100M network transmission |
| Security | Authorized username and password, MAC address binding, HTTPS encryption, and network access control |
| Alarm Event | Storage full, Storage error, External alarm, No storage card, License plate blocklist, Illegal access, Network disconnection, IP conflict |
| Cyber Security | AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot |
| OSD | Camera title, Date & Time |
| Motorcycle vehicle Violation Capture | Captures traffic violations including carrying passenger, not wearing helmet, and wrong-way driving |
| Motor Vehicle Violation Snapshot | Speeding, driving slow, wrong-way driving, illegal lane change |
| Defog | Support |
| Edge Enhancement | Support |
| Traffic Event | Motor vehicle illegal stopping on the roadway, traffic congestion |
| Traffic Flow Detection | Statistics on vehicle flow, average speed, vehicle type, lane occupancy, average time headway, average queue length, and road status |
| Positioning | GPS |
| Image Tampering | Verifies watermarks in videos and images |
| Image Encoding Format | JPEG |
| Gain Scope | 0–100 |
| Time Synchronization | NTP, GPS |
| Target Detection | Motor vehicle, Motorcycle |
| Auto Connect | Support |
| Vehicle Color Recognition | White, Pink, Black, Red, Yellow, Gray, Blue, Green, Deep orange, Purple, Brown, and silver Gray (color recognition is not supported during nighttime) |
| Trigger Mode | Video trigger/ Radar trigger |
| Vehicle Logo | Acura, Alfa Romeo, Ashok Leyland, Aston martin, Audi, Bentley, Benz, BMW, Cadillac, Chevrolet, Citroen, Dacia, Daihatsu, Datsun, Ferrari, Fiat, Force, Ford, GMC, Honda, Hyundai, Infiniti, Iveco, Jaguar, Jeep, Kia, Land, Lexus, Mahindra, Maserati, Mazda, Mercury, MG, Mini, Mitsubishi, Nissan, Peugeot, Porsche, Renault, Rolls-Royce, Seat, Skoda, Smart, Suzuki, Tata, Tesla, Toyota, Volkswagen, Volvo |
| Composite Image | Support combining up to 3 source images, and 1 closeup image into a composite image |
| Bad Pixel Correction | Support |
| ANPR Technology | Adopts developed algorithms to recognize license plate numbers and letters |
| RS-485 | 2, connects to devices such as radars |
| Vehicle Type Recognition | Vehicle head: SUV, Large bus, Sedan, Light truck, Pickup, Heavy truck, Medium truck, Van, Medium bus, MPV Vehicle tail: SUV, Large bus, Sedan, Light truck, Pickup, Heavy truck, Medium truck, Van |
| RS-232 | 2, connects is used for serial debugging and R T G is for connecting to radars |
| Automatic Network Recovery (ANR) | Platform and FTP (SD card is required) |
| OSD Overlay | Time, Address, Device SN, Lane No., Plate number, Plate color, Vehicle logo, Vehicle type, Vehicle color, Vehicle size, Vehicle speed, Country/region, Event (violation name), and motorcycle attributes (Type, Number of people, and Helmet) |
| Audio Input | 1 Channel |
| Audio Output | 1 Channel |
| Alarm Input | 3 Channel |
| Alarm Output | 2 Channels 2 for relay |
| Browser | Microsoft Edge, Chrome: Chrome 41 and earlier, Firefox: Firefox 49 and earlier For Win 10 users, run the browser as administrator |
| Certificates | ISO9001 |
| Power Source | 12-36 VDC 3.33A, PoE |
| Power Consumption | ≤ 13 W |
| Storage | SFTP, NAS, Mirco SD card (Max. 512GB) |
| Weatherproof Standard | IP67 & IK10 |
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity | 10%-90% (RH) |
| Storage Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
| Storage Humidity | 0%-90% (RH) |
| Dimensions | 466.4 mm × 135.8 mm × 134.1 mm |
| Weight | 3.9 kg |
